Activity 4: Tank

; utank.kf
; USER CONTROLLED TANK
;
;   SPACE       - stop                          32
;   w           - start/stop move forard        119
;   s           - start/stop move backward      115
;   a           - rotate left                   97
;   d           - rotate right                  100
;   e           - eat                           101
;   r           - reproduce                     114
;   f           - fire                          102
;   .           - move                          46
;
; trap4 - move          ( -- r)             move in current direction based on thrust
; trap5 - make-spore    (e -- rc)
; trap6 - set thrust    (n -- )             n is: 0 -1 or 1     stopped, backward, forward
; trap7 - shoot         ( -- )
; trap8 - rotate        (n -- r)            n is: 0, -1 or +1
; trap9 - eat           (x y -- rc)         eat
;
; Shape:
; This organism creates a tank like shape. This is
; the morphology:
;
;       JBCD
;        EAFL
;       KGHI
;
;    ####
;     ####
;    ####
;
; It can only EAT and SHOOT from the turret cell
; It breeds from the back cell.
; It can generally Omove and rotate as it wants to.
; Organism cannot heal itself.
;
; A
; B     creates J
; C
; D
; E     - reproducer
; F     creates L
; G     creates K
; H
; I
; J
; K
; L     - turret/eater/shooter
;
; Protected Instructions:
;   R9++ --R9 R9!
;   CSHIFT, CMOVE
;   EAT, SEND-ENERGY, SPAWN
;   MAKE-SPORE
;   GROW, GROW.CB
;
; Modes:
;   - Make EAT permissive: Don't kill cell, just nibble
;   - rotate must use center of organism
;
;
; Principle of operation:
;   * Shoot (trap9) can only happen from L cell
;   * Eating (trap8) can only happen from L cell
;   * Reproduction: (trap7) can only happen from E cell
;   * We use the R9 register to store our cell ID
;   * the cell ID is the code block number we were first redirected to
;
;
;

main:
{
    dnum call directions + call
    2negate
    2dup OMOVE pop
    2dup OMOVE pop
    OMOVE pop

    0 thrust 0 NUMBER!      ; may have been changed by parent reset to initial state
    2 dnum 0 NUMBER!        ; may have been changed by parent reset to initial state

    a_cell call
}

_trap1: { }
_trap2: { }

;
; ( -- thrust)
;
_trap3: { CSLEN 63 <= ?exit thrust call }

;
; Move ( -- rc)
;
;;_trap4:
;;{
;;  DSLEN 60 >= ?exit
;;  CSLEN 60 >= ?exit
;;
;;  dnum call directions + call     ; -- x y
;;  thrust call                     ; -- x y t
;;  swap over                       ; -- x t y t
;;  *                               ; x t y t -- x t y*t
;;  -rot                            ; x t y*t -- y*t x t
;;  *                               ; y*t x t -- y*t x*t
;;  swap                            ; y*t x*t -- x*t y*t
;;  OMOVE
;;}

_trap4:
{
    0 0 OMOVE
}

; make-spore replacement (e -- r)
_trap5:
{
    R9 e_cell <> ?exit
    DSLEN 60 >= ?exit
    CSLEN 60 >= ?exit

    dnum call directions + call 2negate rot MAKE-SPORE
}

; Set Thrust (n -- )
; n is normalized to -1, 0, 1
; -1 means backwards
_trap6:
{
    DSLEN 1 < ?exit
    SIGN thrust 0 NUMBER!
    recompute_move_trap call
}

;
; shoot ( -- )
;
_trap7:
{
    R9 l_cell <> ?exit
    DSLEN 60 >= ?exit
    CSLEN 60 >= ?exit

    dnum call directions + call

    1 5 bullet SPAWN pop
}

;
; rotate (n -- r)
;
_trap8:
{
    DSLEN 60 > ?exit
    CSLEN 60 > ?exit
    DSLEN 1 < ?exit
    do_rotate call
}

;
; eat (x y -- r)
;
_trap9:
{
    R9 l_cell <> ?exit
    EAT
}

recompute_move_trap:
{
    dnum 0 NUMBER
    directions + call
    thrust call
    swap over                       ; -- x t y t
    *                               ; x t y t -- x t y*t
    -rot                            ; x t y*t -- y*t x t
    *                               ; y*t x t -- y*t x*t
    swap                            ; y*t x*t -- x*t y*t
    _trap4 1 NUMBER!
    _trap4 0 NUMBER!
}

do_rotate:
{
    SIGN            ; n
    dup ROTATE
    {
        dnum 0 NUMBER   ; n dnum
        +
        dup 0 <
            { pop 7 }
            {
                dup 7 > { pop 0 } if
            } ifelse
        dnum 0 NUMBER!
        recompute_move_trap call
        1
    } { 0 } ifelse
}

; 0 = stopped, -1 = backwards, 1 = forwards
thrust: { 0 }

; this is the current direction will always be a number
; between 0 and 7.
; (Initial direction corresponds to pointing right)
dnum: { 2 }

;
; Direcetion table for 'dnum'
;
directions:
    { 0 1 }
    { 1 1 }
    { 1 0 }
    { 1 -1 }
    { 0 -1 }
    { -1 -1 }
    { -1 0 }
    { -1 1 }

;
; Create the tank shape
;       JBCD
;        EAFL
;       KGHI
;
a_cell: {
    {
        0
        -1 1    b_cell      GROW.CB not +
        0 1     c_cell      GROW.CB not +
        1 1     d_cell      GROW.CB not +
        -1 0    e_cell      GROW.CB not +
        1 0     f_cell      GROW.CB not +
        -1 -1   g_cell      GROW.CB not +
        0 -1    h_cell      GROW.CB not +
        1 -1    i_cell      GROW.CB not +
        { HALT } if
    } call
    evolve_a_cell call
}

b_cell:
{
    CB R9!
     -1 0 j_cell GROW.CB not { HALT } if
    evolve_b_cell call
}

c_cell: { CB R9! evolve_c_cell call }
d_cell: { CB R9! evolve_d_cell call }
e_cell: { CB R9! evolve_e_cell call }

f_cell:
{
    CB R9!
    1 0 l_cell GROW.CB not { HALT } if
    evolve_f_cell call
}

g_cell:
{
    CB R9!
    -1 0 k_cell GROW.CB not { HALT } if
    evolve_g_cell call
}

h_cell: { CB R9! evolve_h_cell call }
i_cell: { CB R9! evolve_i_cell call }
j_cell: { CB R9! evolve_j_cell call }
k_cell: { CB R9! evolve_k_cell call }
l_cell: { CB R9! evolve_l_cell call }

; move forward and eat
; When the bullet is spawn'd its kforth program contains  the vector the tank
; was moving, we just use that info to derive the direction of the bullet
bullet:
{
    dnum call directions + call

    2dup        ; (x y x y -- )

    { 2dup OMOVE ?loop } call       ; bullet move

    {
        2dup EAT pop
        2dup OMOVE pop      ; ( x y -- x y rc)
        255 NEAREST EAT
        ?loop
    } call

    HALT
}


; ---- protected / unprotected ----

evolve:
evolve_a_cell: { 1 ?loop }
evolve_b_cell: { check_thrust call }
evolve_c_cell: { 1 ?loop }
evolve_d_cell: { 1 ?loop }
evolve_e_cell: { check_reproduce call }
evolve_f_cell: { check_steering call }
evolve_g_cell: { check_fire call }
evolve_h_cell: { 1 ?loop }
evolve_i_cell: { 1 ?loop }
evolve_j_cell: { 1 ?loop }
evolve_k_cell: { TRAP4 pop 1 ?loop }        ; move
evolve_l_cell: { check_fire call }

check_thrust:
{
    KEY-PRESS
    dup 119 = { 1 TRAP6 } if
    dup 115 = { -1 TRAP6 } if
    32 = { 0 TRAP6 } if
    1 ?loop
}

check_steering:
{
    KEY-PRESS
    dup 97 = { -1 TRAP8 pop delay call } if
    100 = { 1 TRAP8 pop delay call } if
    1 ?loop
}

delay: { 50 {1- dup ?loop} call pop }

check_fire:
{
    KEY-PRESS
    dup 102 = { TRAP7 } if
    101 = { 7 NEAREST TRAP9 pop } if
    1 ?loop
}

check_reproduce:
{
    KEY-PRESS
    dup 114 = { ENERGY 5 / TRAP5 pop } if
    46 = { TRAP4 pop } if
    1 ?loop
}
